The MD-ACU was originally develop for a client (Santos) the unit is still under trial in remote part of North QLD. The unit was manufactured in 48 volts and the use of brushless fans to keep current consumption to a limit. The unit works from solar and wind power generation with a diesel generator on automatic standby when power levels drop below 42 volts.
The MD-ACU was designed to run for a minimum of 8000 hours without any servicing to the unit. The condenser design is unique as the fans pull though the base eliminating any debris or vermin/animals to enter the unit internally. The unit is also fitted with a fault sensor output if a GPS or wireless signal is in range this can be configured to indicate a fault in the unit and the capability for the client to then act accordingly and quickly.
Using 48 volt on the MD-ACU provided the unit with very low amp draw with the use of the brushless fans this lowered it more than our expectations. The unit could produce low as 20 amps total in +35 deg C ambient cooling a 3m x 3m x 2m shelter.
Suit – Non-mobile Applications – Remote location – Above &
Underground Corrosive, High Ambient
• Fully self-contained
• Primary function
• 5kW capability
• Vermin proof design
• Wireless fault signal capability
• 24 & 48 volt options
• All brushless IP68 rated fans
