Rencool MD24A6 24 V Electric Compressor dimensional drawing
Rencool MD24A6 24 V Electric Compressor product view 4
Rencool MD24A6 24 V Electric Compressor voltage performance curve
Rencool MD24A6 24 V Electric Compressor speed control curve
Rencool MD24A6 24 V Electric Compressor refrigeration performance curve
Rencool MD24A6 24 V Electric Compressor compressor operating range chart

Rencool MD24A6 24 V Electric Compressor

$2,143.90

Australian dollar ($) - AUD
  • Australian dollar ($) - AUD
  • United States dollar ($) - USD

Prices are shown in AUD. Australian GST is included where applicable.

Power demanding 24 V air-conditioning projects with the Rencool MD24A6. Its 24 cm³/rev electric scroll compressor delivers up to 4.06 kW measured cooling for commercial vehicles, machinery and custom HVAC systems.

Supply
24 V DC
Displacement
24 cm³/rev
THIS PRODUCT ISCompressor only

Build it into a matched refrigerant circuit or use it to replace a compatible compressor.

See what else you need ↓
SKU: MD24A6 Category: Brand:

BUY WITH CONFIDENCE

Is this the right part for your system?

This section separates the product from the rest of the system so you can see what you are buying and what still has to be matched.

THIS PRODUCT IS

Electric refrigerant compressor

BEST FOR

Higher-output 24 V split systems for larger cabins and equipment where up to 4.00 kW reference cooling at 6,000 rpm suits the calculated duty.

Included with this listing

  • Rencool MD24A6 24 V compressor with integrated controller
  • Compressor-side electrical leads/connectors as supplied

Still required for a working system

  • 24 V condenser and evaporator sized for the duty
  • Receiver drier and correctly selected expansion valve
  • HP/LP pressure safety switch
  • MD-series control harness or equivalent reviewed control circuit
  • Compressor bracket, hoses/fittings, main fuse and correctly sized cable

Common options

  • Compressor mounting bracket
  • Matched hose and fitting package
  • Model-specific control harness
  • Application-specific condenser and evaporator upgrades

What may be retained

  • Existing condenser, evaporator, cabin controls and refrigerant lines may be retained only after capacity, condition, refrigerant, oil and connection compatibility are verified.
Technical decision points
Product / modelRencool MD24A6 24 V Electric Compressor
Ordering SKUMD24A6
Product roleElectric refrigerant compressor
Purchase pathAvailable for online checkout when destination freight is returned.
Supply24 V DC; documented operating range 20–31 V
Displacement24 cc/rev
Speed range1,500–6,000 rpm
Reference cooling1.89 / 2.58 / 4.00 kW at 3,000 / 4,000 / 6,000 rpm
Reference input1.02 / 1.36 / 2.16 kW at 3,000 / 4,000 / 6,000 rpm
Rated current90 A at 6,000 rpm
Refrigerant / oil chargeR134a / 120 cc oil charge in the reference data
Compatibility checklist before ordering
  • System voltage and continuous current
  • Required cooling duty at the intended ambient
  • Refrigerant, oil and metering device
  • Suction/discharge connections
  • Control signal and pressure-protection logic

Commonly matched products

Rencool RNC-105 12 / 24 V Remote CondenserRencool EV2208 12 V 5 kW Underdash EvaporatorRencool Receiver Drier with Mounting BracketRencool HP/LP Pressure Safety SwitchRencool MD-Series Wiring & Control HarnessRencool MD-Series Hose & Fitting KitRencool MD18 / MD24 / MD27 Compressor Mounting Bracket

These are common system roles, not a promise that every listed part fits every application. Match voltage, capacity, refrigerant circuit and connections.

Technical documents

MD24A6 drawings and parametersPDFMD24 dimensional drawingPDFMD24 performance chartsPDFMD-series EMC/EMI test summaryPDF

Ordering and delivery

Compressor orders are reviewed against voltage and application details. Lead time is confirmed with the order or quotation. Freight is based on the packed consignment; large or configured products receive a confirmed pack plan before dispatch.

Request a technical quote

SYSTEM BUILDER

What else do I need?

Choose the route that matches your project. The compressor can replace a compatible unit, power a custom split system, or form part of a complete package.

1

Connect to existing A/C

Use the existing condenser, evaporator and controls only after confirming capacity, R134a compatibility, oil management, pressure protection and electrical load.

2

Build a new split system

Add the matched heat exchangers, protection, controls, hoses and mounting hardware shown below.

3

Choose a complete kit

If you do not want to engineer every component, start with a packaged system sized for the cabin and duty cycle.

For a new MD-series split system

1. CondenserChoose the matching 12 V or 24 V RNC-105 version.View product →2. Evaporator & controlsEV2208 is the compact 12 V option; choose a matched-voltage evaporator for other systems.View product →3. Receiver drierRequired in the standard TX-valve circuit.View product →4. Pressure safety switchRequired unless equivalent pressure protection already exists.View product →5. Wiring harnessRecommended to simplify thermostat, relay and safety integration.View product →6. Hose & fitting kitStandard #6, #8 and #10 hose package for a new split system.View product →7. Mounting bracketPurpose-built bracket for MD18, MD24 and MD27 compressors.View product →

Required for a new buildRecommendedApplication dependent

Final system design: A qualified automotive A/C technician must confirm refrigerant charge, TX valve, hose routing, oil balance, pressure settings and electrical cable/fuse sizing.

ENGINEERING & PROCUREMENT

Need this product for a tender or controlled project?

Send the exact model, voltage, duty point, quantities, destination and required drawings or test evidence. The proposal can then refer to one controlled configuration.

Open procurement guide

Product details

Power demanding 24 V air-conditioning projects with the Rencool MD24A6. Its 24 cm³/rev electric scroll compressor delivers up to 4.06 kW measured cooling, giving vehicle builders, fleet operators and equipment manufacturers strong performance without an engine-driven belt.

More cooling capacity, more installation freedom

  • 4.06 kW measured cooling at 6,000 rpm: strong output for commercial vehicles, machinery and larger compact cabins.
  • 24 V electric drive: designed for vehicles and equipment with a correctly sized 24 V charging and battery system.
  • 2,000–6,000 rpm variable speed: balance cooling demand, power use and acoustic performance.
  • Compact 24 cm³/rev scroll platform: place the compressor independently of the engine and position the heat exchangers to suit the build.
  • Rencool validation: qualified performance, IP67 ingress protection, vibration resistance and a 1,012-hour durability program.

Popular applications

  • Trucks, buses, emergency vehicles and commercial fleets
  • Mining, civil, agricultural and off-highway machinery
  • Electric vehicles, hybrid conversions and prototype platforms
  • Motorhomes, expedition vehicles and larger camper builds
  • Marine cabins, mobile workspaces and specialist equipment enclosures
  • Engine-off auxiliary cooling and custom 24 V HVAC systems

MD24A6 technical specifications

Rencool model MD24A6
Compressor type Electric scroll compressor
Motor and controller Brushless DC motor with internal controller and soft start
Rated supply 24 V DC
Operating voltage range 20–31 V DC
Displacement 24 cm³/rev
Operating speed range 2,000–6,000 rpm
Refrigerant R134a
Factory oil charge 100 cc POE 68; verify the supplied compressor label before adding or replacing oil
Nominal compressor mass Approx. 5.5 kg; packed shipping weight is calculated separately
Approximate installation envelope 209 × 135 × 155 mm; allow additional clearance for cables, fittings, airflow and service access
Published enclosure protection IP67

Measured cooling performance

Rencool MD24A6 validation performance
Speed Cooling capacity Input power Working current COP Discharge temperature
3,000 rpm 1.897 kW 0.982 kW 40.91 A 1.931 87.5 °C
4,000 rpm 2.477 kW 1.267 kW 52.79 A 1.955 86.3 °C
6,000 rpm 4.059 kW 2.036 kW 84.83 A 1.993 85.5 °C

Measured on a Rencool MD24A6 validation sample at 24 V nominal supply, 1.570 MPa discharge pressure, 0.296 MPa suction pressure, 10 °C superheat, 5 °C subcooling and 50 °C ambient. Complete-system performance depends on the condenser, evaporator, controls, airflow, refrigerant charge and installation.

MD24A6: cooling and electrical input

Compare cooling output with the compressor’s electrical input at three rated speeds. Fan and blower power are additional.

3,000 rpm

Cooling1.89 kW
Input1.02 kW
4,000 rpm

Cooling2.58 kW
Input1.36 kW
6,000 rpm

Cooling4 kW
Input2.16 kW

R134a; suction pressure 0.196 MPa; discharge pressure 1.47 MPa; superheat 10°C; subcooling 5°C. Nominal compressor ratings at these conditions. Installed cooling also depends on the heat exchangers, airflow and refrigerant circuit.

Speed Cooling Compressor input
3,000 rpm 1.89 kW 1.02 kW
4,000 rpm 2.58 kW 1.36 kW
6,000 rpm 4.00 kW 2.16 kW

MD24A6: cooling across operating temperatures

See how the same compressor’s cooling output changes with evaporating and condensing temperatures. These conditions differ from the nominal speed ratings above.

  • 45°C condensing
  • 50°C condensing
  • 55°C condensing
  • 60°C condensing
  • 65°C condensing
  • 70°C condensing

24 V DC · R134a · 6,000 rpm · ambient 50°C · superheat 10°C · subcooling 5°C. Each line represents a condensing temperature. Table values are approximate readings rounded to 0.05 kW; this is compressor performance, not a complete-system rating.

Condensing kW at −5°C kW at 0°C kW at 5°C kW at 10°C
45°C 3.75 4.60 5.55 6.65
50°C 3.55 4.35 5.25 6.35
55°C 3.35 4.10 5.00 6.00
60°C 3.15 3.90 4.70 5.70
65°C 2.95 3.65 4.40 5.35
70°C 2.75 3.40 4.15 5.00

MD24A6: voltage and compressor speed

Higher discharge pressure requires more voltage to reach the same compressor speed. Apply this graph only to the MD24A6 control version, not a PWM variant.

  • 1.8 MPa gauge
  • 2.2 MPa gauge
  • 2.5 MPa gauge

MD24A6 controller version shown. Discharge pressures are gauge values. These lines show the plotted voltage/speed relationship only; use the operating supply limits in the specifications for electrical design.

Discharge pressure Speed at 20 V Voltage at 6,000 rpm
1.8 MPa (gauge) 5,000 rpm 22 V
2.2 MPa (gauge) 4,000 rpm 23 V
2.5 MPa (gauge) 3,000 rpm 25 V

Noise and vibration data

Speed 10-point sound power Vibration acceleration Validation limit
3,000 rpm 66.9 dB(A) 2.6 m/s² ≤68 dB(A)
4,000 rpm 67.3 dB(A) 4.3 m/s² ≤72 dB(A)
6,000 rpm 74.5 dB(A) 8.1 m/s² ≤78 dB(A)

Noise was measured by a hemispherical 10-point method in a semi-anechoic chamber. Sound power is a laboratory comparison value and is not the same as in-cab sound pressure.

Electrical, control and interface data

Rated drive power 2.0 kW class
Drive working frequency 30–120 Hz published range
Maximum motor torque reference 3.10 N·m
Under-voltage protection reference 20 V
Over-voltage protection reference 31 V
Speed selection Three published speed-select inputs through the control harness; use the current Rencool wiring diagram
Main power connection Dedicated positive and negative high-current conductors; do not use the chassis as the compressor return
Suction port bore 18.3 mm inside diameter × 13 mm depth
Discharge port bore 15.5 mm inside diameter × 17 mm depth

Operating and environmental limits

Published ambient range −35 to +70 °C
Published compressor working-temperature reference −30 to +100 °C
Published storage-temperature reference −40 to +105 °C
Controller-temperature protection reference 120 °C
Discharge-temperature protection reference 115 °C
Safety-valve pressure reference 4.0 MPa
Maximum published compression ratio 8.0:1

These are component-level references. The complete HVAC system must keep pressure, temperature, voltage and current within the limits of every installed component.

2025 validation summary

Ingress protection IP67 qualification: 1 m water immersion for 30 minutes, no water ingress, followed by a successful electrical withstand check
Durability program 1,012 accumulated operating hours across rated, speed-cycling, low-voltage and high-voltage conditions; post-test requirements qualified
Vibration resistance 50–250 Hz in three axes, 294 m/s² acceleration, 18 total test hours; unit remained operational and post-test performance qualified
Sealing performance Measured leak rate below the report limit of 14 g/year
High-temperature resistance 120 °C for 96 ±2 hours under the report method; qualified after inspection
Low-temperature resistance −35 °C for 72 ±2 hours under the report method; qualified after inspection
Damp-heat and thermal cycling Qualified after alternating damp-heat and temperature-cycle testing, including post-test electrical and IP67 checks

System requirements

Mount the MD24A6 upright with the controller uppermost, keep the housing clear of heat sources and maintain cool suction-gas return through the compressor. Run dedicated positive and negative power cables back to the battery and calculate cable size, circuit protection and charging capacity from worst-case current and cable length.

System components required Matched condenser, evaporator, expansion device, receiver-drier, thermostat/control, pressure protection and correctly sized refrigerant lines
Electrical design point Allow for compressor current plus condenser fans, evaporator blower and controls at the highest expected ambient and head pressure
Mounting orientation Upright only, controller uppermost; protect cables and refrigerant lines from abrasion, vibration and radiant heat
Commissioning Leak-test, evacuate, charge and validate operating pressures, voltage and current using qualified air-conditioning personnel

Technical selection: Use the exact compressor model, supply voltage and controller interface. Capacity values apply only at their stated test conditions; size the condenser, evaporator, wiring and protection as one system.

Ready to build your 24 V system?

Select the quantity above and add the Rencool MD24A6 to your basket. Use the measured tables to confirm capacity and current, then size the condenser, evaporator and electrical supply for the cabin volume, ambient temperature and operating duty.

Delivery

Voltage

Product type

How it is used

, ,

Delivery cost Enter your delivery address at checkout to see available shipping services and costs. If no service is shown, request a delivery quote.
Delivery information Shipping, delivery times and returns

Manuals & drawings

View manuals and drawings (8)
  • MD series installation manualJune 2020 · MD series. Match the compressor and controller shown in the manual.
  • MD-B mounting bracket drawingMD-series bracket geometry. Check mounting centres against the selected compressor.
  • MD24A6 voltage and speed curveMD24A6 reference plot at the stated discharge pressures. Applies to the illustrated controller version; not a PWM model specification.
  • MD24A6 cooling capacity curveMD24A6 · 24 V · R134a · 6,000 rpm. Subcooling 5°C, superheat 10°C, ambient 50°C. Compressor performance, not complete-system cooling capacity.
  • MD24A6 refrigerant port drawingReference suction and discharge connection geometry. Match the fittings and full compressor version before installation.
  • MD24A6 front-view drawingReference housing and mounting geometry. Dimensions apply to the illustrated MD24A6 assembly.
  • MD24A6 side-view drawingReference MD24A6 housing, mounting and refrigerant ports. Allow additional space for connections and servicing.
  • MD24A6 top-view drawingReference MD24A6 housing and connector arrangement. The illustrated assembly is distinct from other controller revisions.

Related products

Photography credits

Aircraft: Jelle Vandebeeck, CC BY 2.0. Workboat: Photo: Gordon Leggett / Wikimedia Commons, CC BY-SA 4.0. Caravan: Bahnfrend, CC BY-SA 4.0. Command post: U.S. Army, public domain. These photographs are resized for display and may be cropped to fit the page; the credited photographs retain their original licences. General application photography does not confirm a particular vehicle installation or endorsement.
